Safety net edged with rope, 10 x 10 m
Size
10 x 10 m
Size
10 x 10 m
Mesh size
100 mm
Mesh size
100 mm
Weight per m²
275 g/m²
Safety net system
S (rope-edged safety net)
Knotless sytem-S safety net conforming to EN 1263-1 (rope-edged safety net) made of Polypropylen high tenacity
edged all round with approx. 12 mm, 30 kN rope
Energy absorption: approx. 4.4 kJ = net type A2
GS Test Certificate: 7100004
Properties
Article number
19042-100
Available colours
(01)
(04)
Execution
edged all round with rope
Mesh
square
Material
high tenacity polypropylene, knotless
Size
10 x 10 m
Size
10 x 10 m
Material diameter
4,75 mm
Material diameter
4.75 mm
Mesh size
100 mm
Mesh size
100 mm
Mesh breaking strength
3.00 kN
Energy absorption
4.6 kJ
Tensile Strength of Edged Rope
30 kN
Total Weight
21,20 kg
Weight per m²
275 g/m²
Standards and Rules
BGR 179, DGUV Regel 101-011, DIN EN 1263-1
Net class
A2
Safety net system
S (rope-edged safety net)
Regular Inspection Interval
12 months
Number of test meshes
3 pcs.
Continuous operating temperature
-40 to +80 °C
Melting point
165 °C
Bending strength & abrasion resistance
good
Weather resistance
good
UV-Resistance
300 kly
Tensile strength after two years of climatic influences
90%
Customs tariff number
5608 19 30
